Model NO.: 3061
Warranty: 1 Year
Protection Grade: IP66
Loading Weight: 20kg
Transport Package: Carton
Specification: 47cm*39cm*53cm
Trademark: MG-3061
Origin: Hebei
HS Code: 8529904900
Production Capacity: 5000PCS/Year
Product Description

Outdoor heavy-duty variable speed pan tilt head 3061
Strong wind resistant structural design, power failure self-locking function, stable low-speed operation
Enhanced motor drive, high-strength worm gear and worm gear, high repeatability accuracy
Carrying 20kg
RS422 full duplex communication, supporting angle feedback function (it can be upgraded to TTL232 control)
It can support simultaneous output of two videos or switching outputs
It can be upgraded to a network pan tilt according to needs
It is suitable for monitoring large areas and widely used in forest fire prevention, coastal border defense
Important fields such as cross river (sea) bridges and highways

Product name Intelligent heavy-duty variable speed pan tilt 3061
Product parameters function Horizontal range 0~360 °Continuous rotation, optional 355 ° discontinuous rotation
Horizontal speed 0.01 °~30 °/S
Vertical speed 0.01 °~15 °/S
Load bearing and vertical angle range ±45 ° :20KG
±60 ° :15KG
±90 ° :10KG
Preset position Supports 255 (including special preset positions)
auto cruise support
Auto scan support
Relay output 2 groups (scalable)
Angle feedback PELCO-D supports default query feedback (enabling real-time feedback)
lens control Pan tilt configuration lens preset interface
Lightning surge resistance GB/T17626.5-2008
General specifications Power supply DC24V ±20%
power dissipation â‰¤85W(No heating components)
work environment -25 ºC~+65 ºC <90%RH,(Without condenser or heater)
Communication protocol Pelco-D
Baud rate 2,400/4,800/9,600/19,200 bps
Communication methods RS-485/RS-422/network
Protection level IP66
Pan tilt weight 16Kg
Product size 340mm(L)Ã—206 mm(W)Ã—390mm(H)
material aluminium alloy
Carrying method Top/side loading
other Support for deep customization: protocol docking, special camera control, command tracking, 3D, load upgrading, speed matching, etc
